HPE DL380 Gen10 Rack Server

About the HPE ProLiant DL380 Gen11 Rack Server

The dense HPE DL380 Gen11 Rack Server is ideal for a huge variety of workloads including virtualisation, database, or high-performance computing, and is great for space constrained environments. ..

Able to support the Intel Xeon Scalable 4th and 5th Generation Processor family, DDR5 memory and PCI express 5.0. Full support for up to 3 full height, full length GPU's and accelarators. The DL380 Gen11 delivers security, flexibility, agility, up to 110% performance gain, and a 60% increase in cores over Gen10 Pluss. Vastly increased storage density over DL360 Gen 11.

Configure a HPE DL380 Gen11 for your unique business needs

Available in a range of form factors including 8SFF, 16SFF, 24SFF, 32SFF and 38SFF, and in 8LFF, 12LFF, 16LFF and 20LFF and is compatible with a variety of processors from the Intel Xeon 4th Generation and 5th Generation Scalable range. The HPE DL380 Gen11 Server can be configured to your exact business requirements by using the Intelligent Servers UK industry leading online server build tool, configuring the DL380 Gen11 to your exact business needs couldn’t be easier! Simply click on one of the servers above to start choosing between configurable memory, CPUs, hard drives, power supplies, and more..

Why trust a refurbished HPE DL380 Gen11 from Intelligent Servers?

IntelligentServers.co.uk is a leading reseller of refurbished HP, Dell, IBM, and Cisco enterprise IT hardware supplying thousands of businesses across Europe. We're so confident in all of our HPE ProLiant DL380 Gen11 Rack Servers. We provide a three year warranty with remote support. Contact us at 01423 223 430 or email sales@intelligentservers.co.uk.

Processors Click to view specs

Processor Qty1 or 2 Processor Cores8-Core Min to 64-Core Max Processor GHz1.7GHz to 3.9GHz Processor ModelsIntel Xeon 4th and 5th Generation Scalable

Memory (RAM) Click to view specs

Maximum Capacity8TB (32x 256GB) RAM Speeds4800 MT/s and 5600 MT/s Total DIMM Slots32

Drive Bay Configurations Click to view specs

Drive Bay Capacity24 SFF 2.5" / 12 LFF 3.5" / 2 M.2 NVMe Drive TypesSAS Spinning Disk, SATA SSD, SAS SSD, NVMe SSD Max Capacity (2.5")SAS Disk (91.2TB), SAS SSD (583.3TB), SATA SSD (291.84TB), NVMe SSD (374.4TB) Max Capacity (3.5")SAS/SATA Disk (360TB), SAS SSD (11.5TB), SATA SSD (11.5TB) Max Capacity (EDSFF)NVMe (550.8TB)

OCP Slots Click to view specs

Slot Qty1 or 2 OCP Card Types1Gbit, 10Gbit, 25Gbit, 100Gbit Ethernet / Hardware RAID

PCIE Slots Click to view specs

Full Height Slot Qty8x PCIe 5.0

RAID Controller Types Click to view specs

OCP InternalHardware RAID 4GB-8GB Cache PCIe InternalHardware RAID 8GB Cache PCIe ExternalHardware RAID No Cache RAID0/1/5 Software RAIDVROC No Cache RAID0/1/5/10 ProtocolsSATA 6Gb/s, SAS 12Gb/s & 24Gb/s, NVMe

GPU Capacity Click to view specs

Double-Width/Full-Length3 Single-Width/Full-Length8 Single-Width/3/4-Length0

Power Supplies Click to view specs

Power Suppy Qty1 or 2 Power Supply Wattage800W AC to 2200W AC

View as Grid List

Sort by

Display per page

HPE ProLiant DL380 Gen10 12LFF V1 CTO 2U Rack Server 868705-B21

£804.00 incl vat

HPE ProLiant DL380 Gen10 12LFF V2 CTO 2U Rack Server 868705-B21

£804.00 incl vat

HPE ProLiant DL380 Gen10 24SFF V1 CTO 2U Rack Server 868704-B21

£436.80 incl vat

HPE ProLiant DL380 Gen10 24SFF V2 CTO 2U Rack Server 868704-B21

£436.80 incl vat

HPE ProLiant DL380 Gen10 8LFF V1 CTO 2U Rack Server 868706-B21

£1,125.60 incl vat

HPE ProLiant DL380 Gen10 8LFF V2 CTO 2U Rack Server 868706-B21

£1,125.60 incl vat

HPE ProLiant DL380 Gen10 8SFF V1 CTO 2U Rack Server 868703-B21

£360.00 incl vat

HPE ProLiant DL380 Gen10 8SFF V2 CTO 2U Rack Server 868703-B21

£360.00 incl vat

HPE DL380 Gen10 Rack Server FAQs

About the HPE ProLiant DL380 Gen 10 Rack Server

The HPE DL380 Gen10 Rack Server is a highly secure, 2P 2U rack server engineered for industry-leading performance, offering the perfect balance of expandability and scalability to meet the demands of modern businesses.

Designed for versatility and resilience, a refurbished HPE DL380 Gen10 server is adaptable to a range of workloads, making it an ideal solution for cloud computing, big data analytics, virtualisation, and enterprise applications.

Call us on 01423 223 430 to discuss your HPE rack server needs or contact us online.

Why buy the HPE DL380 Gen10 Rack Server from Intelligent Servers?

At Intelligent Servers, we help customers deploy IT infrastructure to solve their problems while maximising their IT budgets. Our pro-services team provides pre- and post-sales support, while our industry leading free 3-year warranty provides peace of mind. Our after-sales service also includes free hardware replacement during your warranty period with 1 to 3 day delivery across Europe. Feel free to get in touch with our team on 01423 223 430, email sales@intelligentservers.uk or visit our Contact Us page.

What form factors are available for the DL380 Gen10?

The DL380 Gen10 is available in multiple configurations, including: 8SFF (Small Form Factor), 8LFF (Large Form Factor), 12LFF, 16SFF, and 24SFF

Can I customise the HPE DL380 Gen10 to meet my business needs?

Yes! The DL380 Gen10 is fully configurable, allowing you to choose from different CPUs, memory, controllers, hard drives, power supplies, PCIe Network and Storage HBA cards to suit your specific requirements.

What processors are compatible with the DL380 Gen10?

The server supports a variety of 1st & 2nd generation Intel Xeon Scalable processors including: Platinum, Gold, Silver, and Bronze

How much memory can the HPE DL380 Gen10 support?

The HPE ProLiant DL380 Gen10 server supports up to 1.5TB RDIMM Memory or up to 3TB LRDIMM Memory

What storage options are available?

The DL380 Gen10 supports multiple drive configurations, including SFF and LFF drive bays, ensuring high-performance and scalable storage solutions. The HPE DL380 Gen10 can be configured with up to 20SFF NVMe ‘Direct Attached’ NVMe SSD Drives using 3x 8SFF NVMe Backplane Kits.

Is the HPE DL380 Gen10 suitable for cloud and big data applications?

Yes, the DL380 Gen10 is built for cloud computing, big data processing, and enterprise-level applications, offering excellent scalability and performance.

How do I purchase an HPE DL380 Gen10 from Intelligent Servers?

You can configure and purchase your server online using Intelligent Servers' industry-leading online server build tool, or contact their team via live chat, phone (01423 223430), or email (sales@intelligentservers.uk).

Are there alternative HPE ProLiant Gen10 rack servers available?

Yes, Intelligent Servers also offers a range of HPE ProLiant Gen10 servers, including: DL160 Gen10, DL560 Gen10, DL580 Gen10, and DL360 Gen10

Can I return or upgrade my server if my requirements change?

Yes, we offer flexible return and trade-in policies. Contact us to discuss upgrade options if your needs evolve.

How quickly can I receive a fully configured server?

Shipping times depend on the complexity of the configuration. Most servers are dispatched within 1-3 working days. Contact us for expedited options.

Can I arrange for a demo or consultation before purchasing?

Yes, our team can provide a consultation or demo, ensuring the chosen server aligns with your operational needs.

How many CPUs does the HPE DL380 Gen10 support?

It supports up to 2 x Intel Xeon Scalable 1st Generation or 2nd Generation processors: Silver, Gold, or Platinum.

What is the maximum RAM capacity?

You can install up to 1.5TB of RDIMM or up to 3TB using LRDIMM Memory. The server has 24 DIMM slots (12 per processor).

What is the maximum amount of local storage it can support?

The DL380 Gen10 supports up to 72TB Hot Plug SFF SAS Spinning Disk, 60TB Hot Plug SFF SATA Spinning Disk, 311TB Hot Plug LFF SAS or SATA Spinning Disk, 459TB Hot Plug SFF SAS SSD Drives, 230.4TB Hot Plug SFF SATA SSD Drives, 307.2TB Hot Plug SFF NVMe PCIe SSD Drives depending on chassis configuration.

How many PCIe slots are available?

The server offers up to 8 x PCIe 3.0 slots and 1 x FlexLOM Slot, with all slots accessible when 2 CPUs are installed. Slot layout varies by riser configuration and can support GPUs or additional storage controllers.

How many power supply units (PSUs) does it support, and what are the wattage options?

It supports 2 x Hot-Plug Redundant PSUs. Available PSU options include 500W, 800W, 1600W, and 1600W 48VDC. Minimum PSU wattage is 500W and Maximum PSU wattage is 1600W.

What types of NIC cards are compatible, and what speeds are supported?

The server supports FlexibleLOM and Single Height, Double Height and ‘Full Length’ PCIe NICs. Compatible network speeds include 1GbE, 10GbE, 25GbE, 40GbE, and up to 100GbE. NICs from HPE, Intel, Broadcom, and Mellanox are commonly used.

Does the server support hardware RAID controllers?

Yes, the DL380 Gen10 supports HPE Smart Array RAID controllers for hardware RAID configurations.

Do the RAID controllers support SAS, SATA, and NVMe in hardware RAID?

The hardware RAID controllers support SAS and SATA. NVMe drives are typically supported via software RAID or direct PCIe pass-through, not through standard hardware RAID controllers.
