HPE DL360 Gen11 Rack Servers

Processor Qty 1 or 2 Processor Cores8-Core Min to 64-Core Max Processor ModelsProcessor GHz 1.7GHz to 3.9GHzProcessor ModelsIntel Xeon 4th and 5th Generation Scalable

Maximum Capacity8TB (32x 256GB)RAM Speeds4800 MT/s and 5600 MT/sTotal DIMM Slots32

Drive Bay Capacity8+2 (10) Small Form Factor 2.5" / 4 Large Form Factor 3.5" / 2 M.2 NVMeDrive Types SAS Spinning Disk, SATA SSD, SAS SSD, NVMe SSDMax Capacity (2.5") SAS Spinning Disk (24TB), SAS SSD (153.6TB), SATA SSD (76.8TB), NVMe SSD (153.6TB)Max Capacity (3.5")SAS/SATA Spinning Disk (96TB), SAS SSD (3.84 TB), SATA SSD (3.84TB)Max Capacity (EDSFF)NVMe (614.4TB)

Slot Qty1 or 2OCP Card Types 1Gbit, 10Gbit, 25Gbit, 100Gbit Ethernet Adapters / Hardware RAID Controllers

Full Height Slot Qty1x PCIe 5.0Half Height Slot Qty2x PCIe 5.0

OCP InternalHardware RAID 4GB-8GB Cache RAID0/1/5/6/10/50/60PCIe InternalHardware RAID 8GB Cache RAID0/1/5/6/10/50/60PCIe External Hardware RAID No Cache RAID0/1/5Software RAIDVROC No Cache RAID0/1/5/10Supported ProtocolsSATA 6Gb/s, SAS 12Gb/s & 24Gb/s, NVMe

Double-Width/Full-Length)0 Single-Width/Full-Length0Single-Width/Three-Quarter-Length2

Power Suppy Qty1 or 2Power Supply Wattage500W AC, 800W AC, 1000W AC, 1600W AC, 1600W VDC, 1800-2200W AC
